Product Code Description
Box Qty
Carton Qty
DIA06
Drop In Anchor, Zinc plated (includes Setting Tool DIAST06) M6 x 8 x 25mm
100 5000
DIA08
Drop In Anchor, Zinc plated (includes Setting Tool DIAST08) M8 x 10 x 30mm
100 5000
DIA10
Drop In Anchor, Zinc plated (includes Setting Tool DIAST10) M10 x 12 x 40mm
50 5000
DIA12
Drop In Anchor, Zinc plated (includes Setting Tool DIAST12) M12 x 16 x 50mm
50 5000
DIA16
Drop In Anchor, Zinc plated (includes Setting Tool DIAST16) M16 x 20 x 65mm
25 5000
DIA20
Drop In Anchor, Zinc plated (includes Setting Tool DIAST20) M20 x 25 x 80mm
20 5000
Short Drop-In Lipped Drop-In
Coil-Thread Drop-In
Drop-In
Anchor Type Bolt
Anchor Type 6-40 8-45 10-50 12-65 16-80
Maximum total length L [mm] 120 165 220 220 220
Drill hole diameter d
o
[mm] 6 8 10 12 16
Cutting diameter at the upper tolerance limit (max. diameter drill bit)
d
cut
, max ≤
[mm] 6.45 8.45 10.45 12.50 16.50
Effective embedment depth
h
ef
[mm] 40 45 50 65 80
Depth of drilled hole to deepest point
h
1
≥ [mm] 55 65 70 90 110
Diameter of clearance hole in the fxture
d
f
≤ [mm] 7 9 12 14 18
Maximum thickness of fxture
t
fx
,max [mm] 65 100 140 120 95
Installation torque T
inst
[Nm] 8 15 30 50 100 Width across fats S
W
[mm] 10 13 17 19 24 Minimum thickness of concrete member
h
min
[mm] 100 100 100 130 160
Minimum allowable spacing
s
min
[mm] 30 40 50 70 90
Minimum allowable edge distance
c
min
[mm] 40 40 50 70 90
• Sizes from 6, 8, 10, 12, 16 mm. in lengths from 65–201mm
• Available in Zinc or Mech Gal
DROP-IN aNCHOR
WEDGE-aLL ® WEDGE aNCHOR
Product Code Description
Box Qty
C
DIA06
Drop In Anchor, Zinc plated (includes Setting Tool DIAST06) M6 x 8 x 25mm
100
DIA08
Drop In Anchor, Zinc plated (includes Setting Tool DIAST08) M8 x 10 x 30mm
100
DIA10
Drop In Anchor, Zinc plated (includes Setting Tool DIAST10) M10 x 12 x 40mm
50
DIA12
Drop In Anchor, Zinc plated (includes Setting Tool DIAST12) M12 x 16 x 50mm
50
DIA16
Drop In Anchor, Zinc plated (includes Setting Tool DIAST16) M16 x 20 x 65mm
25
DIA20
Drop In Anchor, Zinc plated (includes Setting Tool DIAST20) M20 x 25 x 80mm
20
Short Drop-In Lipped Drop-In
Coil-Thre Drop-In
Drop-In
Anchor Type Bolt
Anchor Type 6-40 8-45 10-50 12-65
Maximum total length L [mm] 120 165 220 220
Drill hole diameter d
o
[mm] 6 8 10 12
Cutting diameter at the upper tolerance limit (max. diameter drill bit)
d
cut
, max ≤
[mm] 6.45 8.45 10.45 12.50
Effective embedment depth
h
ef
[mm] 40 45 50 65
Depth of drilled hole to deepest point
h
1
≥ [mm] 55 65 70 90
Diameter of clearance hole in the fxture
d
f
≤ [mm] 7 9 12 14
Maximum thickness of fxture
t
fx
,max [mm] 65 100 140 120
Installation torque T
inst
[Nm] 8 15 30 50 Width across fats S
W
[mm] 10 13 17 19 Minimum thickness of concrete member
h
min
[mm] 100 100 100 130
Minimum allowable spacing
s
min
[mm] 30 40 50 70
Minimum allowable edge distance
c
min
[mm] 40 40 50 70
• Sizes from 6, 8, 10, 12, 16 mm. in lengths from 65–201mm
• Available in Zinc or Mech Gal
DROP-IN aNCHOR
