« Previous Page Table of Contents Next Page »TITEN HD ® HEavy DUTy SCREW aNCHOR FOR CRaCKED aND UNCRaCKED CONCRETE
1 ⁄
2 " min.
Serrated teeth on the tip of the Titen HD ® screw anchor facilitate cutting and reduce installation torque.
ETA
European Technical Approval Option 1
Product Code Description
Box Qty
Carton Qty
THD08080MG
Titen HD ® Screw Anchor, Mechanically Galvanised M8x80
50 200
THD08100MG
Titen HD ® Screw Anchor, Mechanically Galvanised M8 x100
50 200
THD08120MG
Titen HD ® Screw Anchor, Mechanically Galvanised M8 x120
50 200
THD08140MG
Titen HD ® Screw Anchor, Mechanically Galvanised M8 x 140
50 200
THD10080MG
Titen HD ® Screw Anchor, Mechanically Galvanised M10 x 80
50 200
THD10090MG
Titen HD ® Screw Anchor, Mechanically Galvanised M10 x 90
50 200
THD10100MG
Titen HD ® Screw Anchor, Mechanically Galvanised M10 x 100
50 200
THD10120MG
Titen HD ® Screw Anchor, Mechanically Galvanised M10 x 120
50 200
THD10140MG
Titen HD ® Screw Anchor, Mechanically Galvanised M10 x 140
50 200
THD10160MG
Titen HD ® Screw Anchor, Mechanically Galvanised M10 x 160
50 200
THD12075MG
Titen HD® Screw Anchor, Mechanically Galvanised M12 x 75
20 100
TDH12110MG
Titen HD ® Screw Anchor, Mechanically Galvanised M12 x 110
20 100
THD12130MG
Titen HD ® Screw Anchor, Mechanically Galvanised M12 x 130
20 100
THD12150MG
Titen HD ® Screw Anchor, Mechanically Galvanised M12 x 150
20 100
THD16130MG
Titen HD ® Screw Anchor, Mechanically Galvanised M16 x 130
10 50
THD16150MG
Titen HD ® Screw Anchor, Mechanically Galvanised M16 x 150
10 50
THD20150MG
Titen HD ® Screw Anchor, Mechanically Galvanised M20 x 150
5 25
THD20170MG
Titen HD ® Screw Anchor, Mechanically Galvanised M20 x 170
5 25
Also available in zinc plate.
The proprietary design of the threads on the Titen HD anchor hold the key to its performance. During installation, hardened cutting teeth at the tip of the anchor undercut the concrete allowing the rest of the threads to follow with very little friction. The result is a continuous mechanical interlock between the anchor and base material that requires little installation torque.
289
