OZBROACH HIGH SPEED STEEL CUTTERS

IMPERIAL SIZES & HOLDERS

JETBROACH

OZBROACH

• Made in Australia

• Made of quality high speed steel

• No tools needed for replacement with Atra Ace Machine • Self-centering to extend cutter life • Single pass cutting needs no pilot hole

• Only the edge of the hole is cut, thus reducing drilling tim • Produces less swarf than conventional drilling

Cutter Dia. Model No. Cutter Dia. Model N

25mm Depth 50mm Depth

12mm OT12256 12mm OT1250 13mm OT13256 13mm OT13506 14mm OT14256 14mm OT14506 15mm OT15256 15mm OT15506 16mm OT16258 16mm OT16508 17mm OT17258 17mm OT17508 18mm OT18258 18mm OT18508 19mm OT19258 19mm OT19508 20mm OT20258 20mm OT20508 21mm OT21258 21mm OT21508 22mm OT22258 22mm OT22508 23mm OT23258 23mm OT23508 24mm OT24258 24mm OT24508 25mm OT25258 25mm OT25508 26mm OT26258 26mm OT26508 27mm OT27258 27mm OT27508 28mm OT28258 28mm OT28508 29mm OT29258 29mm OT29508 30mm OT30258 30mm OT30508 31mm OT31258 31mm OT31508 32mm OT32258 32mm OT32508 33mm OT33258 33mm OT33508 34mm OT34258 34mm OT34508 35mm OT35258 35mm OT35508 36mm OT36258 36mm OT36508 37mm OT37258 37mm OT37508 38mm OT38258 38mm OT38508 39mm OT39258 39mm OT39508 40mm OT40258 40mm OT40508 41mm OT41258 41mm OT41508 42mm OT42258 42mm OT42508 43mm OT43258 43mm OT43508 44mm OT44258 44mm OT44508 45mm OT45258 45mm OT45508 46mm OT46258 46mm OT46508 47mm OT47258 47mm OT47508 48mm OT48258 48mm OT48508 49mm OT49258 49mm OT49508 50mm OT50258 50mm OT50508 Sizes 51mm - 65mm diameter available in JETBROACH (Tungsten Carbide)

HIGH SPEED STEEL LOCATING PINS

Suit OZBROACH High Speed Steel Cutters

25mm Depth 6mm Ø NAP0625 50mm Depth 6mm Ø NAP0650 25mm Depth 8mm Ø NAP0825 50mm Depth 8mm Ø NAP0850 6mm Pins suit sizes 12mm - 15mm dia. 8mm Pins suit sizes 16mm - 50mm dia.

H igH S peed S teel C utterS

TM H igH S peed S teel C utterS

F eatures oF

TM cutters

Tungsten Carbide Tipped Annular Cutters

• Can be run at higher feed and speeds to produce excellent quality and accuracy of holes • No dead point • Peripheral cutting

• For use on Boring Machine spindles, lathes and Magnetic Drill Stands

Sizes Available

Jetbroach TCT Cutters

DxL - Diam. 12 - 17 x 25mm (L) DxL - Diam. 18 - 35 x 35mm (L) DxL - Diam. 12 - 65 x 50mm (L) DxL - Diam. 18 - 55 x 75mm (L)

Ozbroach Imperial Sizes

OZBROACH

1/2” x 25mm IMP1/2”X25X6MM 3/4” x 25mm IMP3/4”X25X8MM 5/8” x 25mm IMP5/8”X25X8MM 1” x 25mm IMP1”X25X8MM

BHM JETBROACH HOLDERS

Model No. Specifcations Morse Taper

BHM JETBROACH HOLDERS

BHM02035 35Ø - 35 Capacity #2 Morse Taper BHM03050 65Ø - 50 Capacity #3 Morse Taper BHM13075 50 - 100Ø x 75 DOC #3 Morse Taper BHM14075 50 - 100Ø x 75 DOC #4 Morse Taper

MADEINJAPAN
